65" Diagonal Class CDE14 Series LED-backlit LCD display - digital signage - with built-in media player / optional slot-in PC capability - 4K UHD (2160p) 3840 x 2160 - direct-lit LED - with ViewSonic VB-WIFI-005 Adapter
| Main Specifications | |
|---|---|
| Product Description | ViewSonic CDE6514 CDE14 Series - 65" LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display with built-in media player / optional slot-in PC capability |
| Diagonal Class | 65" |
| Commercial Use | Yes - digital signage |
| Bundled with | ViewSonic VB-WIFI-005 Adapter |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Input Video Formats | 480i, 480p, 720p, 1080i, 1080p, 4K, 576p |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | LAN |
| PC Interface | Serial RS-232, USB-C |
| Technology | ADS |
| LCD Backlight Technology | Direct-lit LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Crestron Connected Certified, AMX Certified, Extron Certified |
| Picture Enhancements | Color temperature adjustment, Blue Light Filter, Noise Reduction |
| Speaker System | 2 speakers |
| Storage Capacity | 32 GB |
| USB | Yes |
| Included Accessories | Remote control, RS232 adapter, 4 screws, batteries |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 85.1 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) | 57.6 in x 3.2 in x 33 in |
| Weight | 52.69 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 158.2 Watt |
| Power Consumption Operational | 85.1 Watt |
| Diagonal Class | 65" |
| Commercial Use | Yes - digital signage |
| Bundled with | ViewSonic VB-WIFI-005 Adapter |
| Combined With | Built-in media player / optional slot-in PC capability |
| Series | CDE14 Series |
| Operating System | Android 14 AOSP |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | Serial RS-232, USB-C |
| Modes | Zoom Mode, portrait mode, landscape mode, Picture mode |
| Picture Enhancements | Color temperature adjustment, Blue Light Filter, Noise Reduction |
| Width | 57.6 in |
| Depth | 3.2 in |
| Height | 33 in |
| Weight | 52.69 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years ¦ Limited warranty - backlight - 3 years |
| Miscellaneous | |
| Included Accessories | RS232 adapter, 4 screws, batteries |
| Cables Included | HDMI cable - 10 ft |
| Compliant Standards | cTUVus, FCC, RoHS |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Display | |
| LCD Display Technology | ADS |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct-lit LED |
| Coating | Anti-glare, 3H Hard, 25% haze |
| Image Contrast Ratio | 1200:1 |
| Dynamic Contrast Ratio | 2000:1 |
| Brightness | 350 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 11 ms |
| Backlight Life | 30,000 hour(s) |
| Commercial Features | Crestron Connected Certified, AMX Certified, Extron Certified |
| Operation Hours / Days | 16 / 7 |
| Additional Features | WiFi slot, picture-in-picture (PIP), 1.07 billion colors, 8-bit+FRC, 16/7 operation time |
| Connections | |
| Connector Type | 3 x HDMI input ¦ RS-232 input ¦ SPDIF output ¦ Audio line-out ¦ LAN ¦ 2 x USB 2.0 ¦ USB-C with 15W Power Delivery |
| Video Features | |
| Input Video Formats | 480i, 480p, 720p, 1080i, 1080p, 4K, 576p |
| Remote Control | |
| Type | Remote control |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Battery Included Qty | 2 |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 Watt |
| Speakers | 2 x speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 64.1 in |
| Depth (Shipping) | 7.3 in |
| Height (Shipping) | 37.1 in |
| Weight (Shipping) | 70.99 lbs |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| LAN Protocol | Fast Ethernet |
| Wi-Fi Protocol | 802.11ax, 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac |
| Bluetooth Version | Bluetooth 5.2 |
| Stands & Mounts | |
| Flat Panel Mount Interface | 600 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| Configuration | MT9681 (Quad-Core ARM Cortex-A73) - 4 GB DDR4 - 32 GB - ARM Mali-G57 MC1 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
