Hard drive - Enterprise - 8 TB - internal - 3.5" - SATA 6Gb/s - 7200 rpm - buffer: 256 MB
| Main Specifications | |
|---|---|
| Product Description | Seagate Exos 7E10 ST8000NM017B - hard drive - Enterprise - 8 TB - SATA 6Gb/s |
| Type | Hard drive - internal |
| Capacity | 8 TB |
| Form Factor | 3.5" |
| Interface | SATA 6Gb/s |
| Data Transfer Rate | 6 GBps |
| Buffer Size | 256 MB |
| Spindle Speed | 7200 rpm |
| Drive Class | Enterprise |
| Features | Advanced format 512e, advanced format 4Kn, Super Parity, Low Halogen, PowerChoice, PowerBalance, Advanced Write Caching, Seagate Fast Format, 24x7 availability |
| Dimensions (WxDxH) | 4 in x 5.8 in x 1 in |
| Weight | 25.25 oz |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Hard drive - internal |
| Capacity | 8 TB |
| Form Factor | 3.5" |
| Interface | SATA 6Gb/s |
| Buffer Size | 256 MB |
| Bytes per Sector | 512 |
| Features | Advanced format 512e, advanced format 4Kn, Super Parity, Low Halogen, PowerChoice, PowerBalance, Advanced Write Caching, Seagate Fast Format, 24x7 availability |
| Width | 4 in |
| Depth | 5.8 in |
| Height | 1 in |
| Weight | 25.25 oz |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Compliant Standards | REACH, RoHS |
| OEM Manufacturer Equivalent Part Number | Seagate ST8000NM017B |
| Power | |
| Power Consumption | 7.06 Watt (idle) ¦ 11.03 Watt (random read) |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 140 °F |
| Shock Tolerance (operating) | 40 g @ 2 ms |
| Shock Tolerance (non-operating) | 150 g @ 1 ms |
| Vibration Tolerance (non-operating) | 5 g @ 10-500 Hz |
| Performance | |
| Drive Class | Enterprise |
| Drive Transfer Rate | 6 GBps (external) |
| Internal Data Rate | 255 MBps |
| Average Latency | 4.16 ms |
| Spindle Speed | 7200 rpm |
| Reliability | |
| MTBF | 2,000,000 hours |
| 24x7 Operation | Yes |
| Non-Recoverable Errors | 1 per 10^15 |
| Expansion & Connectivity | |
| Interfaces | 1 x SATA 6 Gb/s |
| Compatible Bay | 3.5" |
