Conference camera - PTZ - color - 8 MP - 1920 x 1080 - 1080p - motorized - wired - HDMI - LAN - USB 3.1 Gen 1 - MJPEG, H.264, YUV, YUV2 - DC 12 V / PoE Plus
| Main Specifications | |
|---|---|
| Product Description | AVer CAM520 Pro3 - conference camera |
| Device Type | Conference camera - pan / tilt / zoom |
| Camera Mount Type | Wall mount, ceiling mount |
| Dimensions (WxDxH) | 5.6 in x 6 in x 7.2 in |
| Weight | 3.24 lbs |
| Connectivity Technology | Wired |
| Camera | Color |
| Optical Zoom | 12 x |
| Max Resolution | 1920 x 1080 |
| Video Modes | 1080p |
| Optical Sensor Type | WDR CMOS 8 MP |
| Focal Length Control | Motorized zoom |
| Focal Length | 3.9 mm - 46.8 mm |
| Focus Adjustment | (min distance 3.3 ft) |
| Lens Iris | F/1.6-2.8 |
| Tilting Range (degree) | -30 to +90 |
| Interfaces | USB 3.1 Gen 1, HDMI, LAN |
| Control Interface | RS-232 |
| Software Certification | Zoom Certified |
| Cables Included | USB cable - external - 16.4 ft ¦ 1 - serial adapter - external |
| Voltage | AC 100-240 V, DC 12 V / PoE Plus |
| Features | VISCA over IP, SmartFrame, PoE+ support, USB video class (UVC 1.1), USB video class (UVC 1.5), 10 preset positions (RS-232), IP Streaming |
| Manufacturer Warranty | 3-year warranty |
| Environmental Parameters (operating) | 32 °F - 104 °F; 20 - 80% relative humidity |
| General | |
| Device Type | Conference camera |
| Camera Mount Type | Wall mount, ceiling mount |
| Connectivity Technology | Wired |
| Width | 5.6 in |
| Depth | 6 in |
| Height | 7.2 in |
| Weight | 3.24 lbs |
| Expansion / Connectivity | |
| Ports | USB 3.1 Gen 1 - 9 pin USB Type B ¦ Serial RS-232 - 8 pin mini-DIN ¦ LAN/power - RJ-45 ¦ HDMI output |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advanced replacement - 3 years |
| Miscellaneous | |
| Included Accessories | Remote control, wall mount bracket, power adapter, tripod screw, QR code card |
| Cables Included | USB cable - external - 16.4 ft ¦ 1 x serial adapter - external |
| Software Certification | Zoom Certified |
| Compliant Standards | IEEE 802.3at |
| Power | |
| Power Requirements | DC 12 V / PoE Plus - 2 A |
| Power Device | Power adapter - external AC 100-240 V (50/60 Hz) |
| Software / System Requirements | |
| OS Required | Apple macOS 10.14.x or later, Microsoft Windows 7 / 10 / 11, Google Chrome OS 94 or later |
| System Requirements Details | Core i5 - 3.2 GHz - RAM 8 GB |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Relative Humidity (operating) | 20 - 80% |
| Camera | |
| Type | Color - pan / tilt / zoom |
| Digital Video Format | MJPEG, H.264, YUV, YUV2 |
| Max Digital Video Resolution | 1920 x 1080 |
| Video Modes | 1080p |
| Video Capture | 1280 x 720 @ 60 fps ¦ 320 x 180 @ 30 fps ¦ 320 x 240 @ 30 fps |
| Features | VISCA over IP, SmartFrame, PoE+ support, USB video class (UVC 1.1), USB video class (UVC 1.5), 10 preset positions (RS-232), IP Streaming |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 10.1 in |
| Shipping Depth | 10.1 in |
| Shipping Height | 10.8 in |
| Shipping Weight | 7.35 lbs |
| Lens Construction | |
| Type | Motorized zoom |
| Optical Zoom | 12 x |
| Focal Length | 3.9 mm - 46.8 mm |
| Lens Iris | F/1.6-2.8 |
| Min Focus Distance | 3.3 ft |
| Horizontal Field of View (degree) | 72.8 |
| Vertical Field of View (degree) | 44.1 |
| Diagonal Field of View (degree) | 80.5 |
| Image Sensor | |
| Type | 8 MP WDR CMOS |
| Interfaces | |
| Video | HDMI |
| Network Interface | LAN |
| Network Protocols | RTSP, RTMP, VISCA |
| Computer Interface | USB 3.1 Gen 1 |
| Control Interface | RS-232 |
| Tilting | |
| Range (degree) | -30 to +90 |
