Router - 8-port switch - GigE - WAN ports: 2 - rack-mountable - BTO
| Main Specifications | |
|---|---|
| Product Description | HPE FlexNetwork MSR2003X - router - desktop, rack-mountable |
| Device Type | Router - 8-port switch (integrated) |
| Enclosure Type | Desktop, rack-mountable - 1U |
| WAN Ports Qty | 2 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Performance | Throughput: 4 Mpps |
| Capacity | IPv4 routing table entries: 300000 ¦ IPv6 routing table entries: 300000 ¦ IPv4 forwarding table entries: 300000 ¦ IPv6 forwarding table entries: 300000 |
| Network / Transport Protocol | TCP/IP, L2TP, RSVP, NTP, PPPoE, NTPv3 |
| Routing Protocol | OSPF, RIP, BGP-4, IS-IS, RIP-2, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, RIPng |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, HTTP, SSH, MIB |
| Features | Port mirroring, Weighted Fair Queuing (WFQ), sFlow, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), User Datagram Protocol (UDP), Multicast Listener Discovery (MLD), Address Resolution Protocol |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Power | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 14.2 in x 11.8 in x 1.7 in |
| Weight | 6.83 lbs |
| Localization | English / United States |
| Pricing Type | BTO |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Router - 8-port switch (integrated) |
| Enclosure Type | Desktop, rack-mountable - 1U |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Performance | Throughput: 4 Mpps |
| Capacity | IPv4 routing table entries: 300000 ¦ IPv6 routing table entries: 300000 ¦ IPv4 forwarding table entries: 300000 ¦ IPv6 forwarding table entries: 300000 |
| Network / Transport Protocol | TCP/IP, L2TP, RSVP, NTP, PPPoE, NTPv3 |
| Routing Protocol | OSPF, RIP, BGP-4, IS-IS, RIP-2, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, RIPng |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, HTTP, SSH, MIB |
| Encryption Algorithm | MD5, TLS |
| Authentication Method | RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features | Port mirroring, Weighted Fair Queuing (WFQ), sFlow, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), User Datagram Protocol (UDP), Multicast Listener Discovery (MLD), Address Resolution Protocol |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, UL 60950-1, IEC 60950-1, FCC Part 22, EN 62311, EN 300 328, EN 301 489-1, EN 60950-1/A11, EN 301 489-17, ETSI EN 300 386, EN 301 908-1, EN 301 511, CAN/CSA C22.2 No. 60950-1 |
| Processor | 1 x Marvell ARM64 2.2 GHz |
| RAM | 4 GB DDR4 SDRAM |
| Flash Memory | 4 GB |
| Expansion / Connectivity | |
| Interfaces | LAN: 8 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 3 x 10Gb Ethernet - SFP+ ¦ 2 x SFP (mini-GBIC) ¦ USB 2.0: 1 x ¦ Console: 1 x RJ-45 |
| Expansion Slots | 2 (total) / 2 (free) x Smart Interface Card (SIC) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| MTBF | 130 years |
| Pricing Type | BTO |
| Localization | English / United States |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 14.2 in |
| Depth | 11.8 in |
| Height | 1.7 in |
| Weight | 6.83 lbs |
