Hewlett Packard Enterprise - HPE NC570C

Network adapter - PCI-X - InfiniBand - 4x InfiniBand (SFF-8470) - 2 ports - for ProLiant DL140 G2, DL145 G2, DL320 G3, DL360 G4, DL360 G4p, DL380 G4, DL385, DL580 G3

Hewlett Packard Enterprise
376158-B21
0829160630724
N/A
New

Price: $98.25

MSRP: $98.25
Total Available: 1

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HPE NC570C - network adapter - PCI-X - 2 ports
Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type PCI-X / 133 MHz
PCI Specification Revision PCI-X 1.0
Bus Voltage 3.3 V
Dimensions (WxDxH) 2.5 in x 6.6 in
Ports Qty 2 ports
Cabling Type 4x InfiniBand (SFF-8470)
Data Link Protocol InfiniBand
Data Transfer Rate 10 Gbps
Processor 1 x Mellanox InfiniRISC
RAM 128 MB
System Requirements SuSE Linux Enterprise Server 8, Red Hat Enterprise Linux 2.1, Red Hat Enterprise Linux 3
Designed For ProLiant 1200, DL140, DL140 G2, DL145, DL145 G2, DL320 G3, DL360 G4, DL360 G4p, DL380 G4 High Performance, DL385, DL580 G2, DL580 G3, DL585, DL740
General
Device Type Network adapter - 2 ports
Form Factor Plug-in card
Interface (Bus) Type PCI-X / 133 MHz
PCI Specification Revision PCI-X 1.0
Bus Voltage 3.3 V
Expansion / Connectivity
Interfaces 2 x network - microGiGaCN
Compatible Slots 1 x PCI-X / 133 MHz
Miscellaneous
Compliant Standards FCC Class B certified, CISPR 22 Class B, EN 60950, IEC 60950, UL 60950, CSA 22.2 No. 60950
Networking
Connectivity Technology Wired
Cabling Type 4x InfiniBand (SFF-8470)
Data Link Protocol InfiniBand
Data Transfer Rate 10 Gbps
Features Half duplex mode, full duplex mode
Software / System Requirements
Software Included Driver
OS Required SuSE Linux Enterprise Server 8, Red Hat Enterprise Linux 2.1, Red Hat Enterprise Linux 3
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 131 °F
Humidity Range Operating 0 - 85%
Processor / Memory
Processor 1 x Mellanox InfiniRISC
RAM 128 MB
Dimensions & Weight
Width 2.5 in
Depth 6.6 in
Compatibility Information
Designed For HPE ProLiant 1200, DL140, DL140 G2, DL145, DL145 G2, DL320 G3, DL360 G4, DL360 G4p, DL380 G4 High Performance, DL385, DL580 G2, DL580 G3, DL585, DL740
