UPS (rack-mountable) - AC 100-125 V - 2400 Watt - 3000 VA - 1-phase - 7 Ah - RS-232, USB - output connectors: 7 - active PFC - 2U - silver
| Main Specifications | |
|---|---|
| Product Description | CyberPower Essential OL3KRM - UPS - 2400 Watt - 3000 VA |
| Device Type | UPS - active Power Factor Correction (PFC) - rack-mountable |
| Rack Size | 2U |
| Weight | 48.28 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 100-125 V |
| Output Voltage | AC 100/110/115/120/125 V ± 2% |
| Power Capacity | 2400 Watt / 3000 VA |
| Input Connectors | 1 x power NEMA 5-30P |
| Output connectors | 6 x power NEMA 5-20R ¦ 1 x power NEMA L5-30R |
| Battery | Lead acid - 7 Ah |
| Batteries Qty | 4 |
| Run Time (Up To) | 2.2 min at full load |
| Networking | RS-232, USB |
| Remote Management Protocol | SNMP, HTTP |
| Color | Silver |
| Dimensions (WxDxH) | 17.1 in x 18.3 in x 3.4 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - active Power Factor Correction (PFC) - rack-mountable |
| Height (Rack Units) | 2U |
| Color | Silver |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ 1 x EPO (emergency power off) |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | Power cable 10 ft ¦ USB cable - external ¦ Serial cable - external |
| Rack Mounting Kit | Included |
| Equipment Protection Value | 400000 US Dollars |
| Features | Metal housing, double conversion, Eco-Mode, integrated backfeed protection, hot-swappable batteries, straight plug, internal bypass, 3:1 max crest factor, auto-sensing, adjustable output voltage, overload protection, cold-start function, short-circuit protection, EMI/RFI filtering, audible alarm, emergency power off, Human Interface Device (HID) support, LCD display, LED indicators, firmware upgradable |
| Compliant Standards | RoHS, UL 1778, CSA C22.2 No. 107.3, FCC Part 15 A |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Remote Management Protocol | SNMP, HTTP |
| Software / System Requirements | |
| Software Included | PowerPanel Business Edition |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% RH (non-condensing) |
| Sound Emission | 55.3 dB |
| Battery | |
| Quantity | 4 |
| Technology | Lead acid |
| Voltage Provided | 12 V |
| Capacity | 7 Ah |
| Run Time (Up To) | 7.5 min at half load ¦ 2.2 min at full load |
| Recharge Time | 4 hours |
| Transfer Time | 0 ms |
| Features | Hot-swappable, sealed |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 100-125 V |
| Input Voltage Range | AC 60 - 150 V |
| Frequency Provided | 50/60 Hz ± 10Hz |
| Input Wiring | 1-phase |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-30P |
| Power Output Connectors Details | 6 x power NEMA 5-20R ¦ 1 x power NEMA L5-30R |
| Output Voltage | AC 100/110/115/120/125 V ± 2% - 50/60 Hz |
| Power Capacity | 2400 Watt / 3000 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 710 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 96% Eco mode |
| Power Factor (PF) | 0.99 |
| Total Harmonic Distortion (THD) | 3 % |
| Dimensions & Weight | |
| Width | 17.1 in |
| Depth | 18.3 in |
| Height | 3.4 in |
| Weight | 48.28 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 22.1 in |
| Shipping Depth | 22.4 in |
| Shipping Height | 9.4 in |
| Shipping Weight | 56.66 lbs |
| Sustainability Information | |
| ENERGY STAR | Yes |
