Server - rack-mountable 1U - 1-way - 1 x Xeon Silver 4514Y / up to 3.4 GHz - RAM 64 GB - SATA/SAS/NVMe - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet - no OS - monitor: none
| Main Specifications | |
|---|---|
| Product Description | HPE ProLiant DL320 Gen11 - rack-mountable Xeon Silver 4514Y 2 GHz - 64 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 1U |
| Server Scalability | 1-way |
| Processor | 1 x Intel Xeon Silver 4514Y / 2 GHz (up to 3.4 GHz, (16-core) |
| Processor Main Features | Intel Turbo Boost Technology |
| Cache Memory | 30 MB L3 cache |
| Cache Per Processor | 30 MB |
| RAM | 64 GB (installed) / 2.04 TB (max) - DDR5 SDRAM - Advanced ECC |
| Storage Controller | RAID (HPE NS204i-u) |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Video Memory | 16 MB |
| Networking | 1GbE |
| Power Redundancy | Yes |
| OS Provided | No operating system |
| Software Included | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
| Dimensions (WxDxH) | 17.1 in x 23.8 in x 1.7 in |
| Environmental Standards | ENERGY STAR Qualified |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Built-in Devices | LED panel |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability | 1-way |
| Hot-Swap Bays Qty | 8 |
| Expansion / Connectivity | |
| Bays | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Slots | 2 (total) / 2 (free) x PCIe 5.0 x16 - half-length, full-height ¦ 1 (total) / 0 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode) |
| Interfaces | 1 x HPE iLO (1 in front) (service port) ¦ 3 x USB 3.2 Gen 1 (1 front, 2 rear) ¦ 1 x VGA (1 rear) ¦ 2 x LAN (Gigabit Ethernet) (2 rear) |
| Miscellaneous | |
| Compliant Standards | ACPI 6.3, PCIe 5.0, SMBIOS 3.2, Redfish API, AES, Triple DES, TLS v1.2, DMTF, Active Directory v1.0, ASHRAE Class A4, ASHRAE Class A3, UEFI 2.7, FIPS 140-2, WEEE 2002/95/EC, IPv6 Ready, PCI DSS |
| RAM | |
| Installed Size | 64 GB (installed) / 2.04 TB (max) |
| Technology | DDR5 SDRAM - Advanced ECC |
| Effective Memory Speed | 4800 MT/s |
| Rated Memory Speed | 4800 MT/s |
| Form Factor | DIMM 288-pin |
| Slots | 16 (total) / 14 (empty) |
| Features | Registered, HPE SmartMemory, slots 9 - 16 are available in two-processor configuration only |
| Configuration Features | 2 x 32 GB |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM5720 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0, SNMP 3 |
| Remote Management Controller | Integrated Lights-Out 6 |
| Features | ACPI support, PXE support, Wake on LAN (WoL) |
| Power | |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-240 V |
| Power Provided | 800 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Storage Controller | |
| Type | 1 x RAID |
| Storage Controller Name | HPE NS204i-u |
| Channel Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Cache Memory | |
| Installed Size | L3 cache - 30 MB |
| Cache Per Processor | 30 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.1 in |
| Depth | 23.8 in |
| Height | 1.7 in |
| Processor / Chipset | |
| CPU | Intel Xeon Silver 4514Y |
| Clock Speed | 2 GHz |
| Max Turbo Speed | 3.4 GHz |
| Number of Cores | 16-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Intel Turbo Boost Technology |
| Chipset Type | Intel C741 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 4.0 |
