AI PC, AI Workstation - tower 4U - no CPU - RAM 0 GB - no HDD - no graphics - Gigabit Ethernet - no OS - monitor: none - black - CTO
| Main Specifications | |
|---|---|
| Product Description | HP Workstation Z2 G1i - tower - AI PC, AI Workstation - no CPU - 0 GB - no HDD |
| Type | Workstation - tower - AI PC, AI Workstation |
| Height (Rack Units) | 4U |
| Processor | No CPU |
| Processor Socket | LGA1851 Socket |
| RAM | 0 GB DDR5 SDRAM |
| Storage Controller | SATA/NVMe (SATA 6Gb/s / PCIe 4.0 x4 (NVMe)) |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | No graphics |
| Networking | 1GbE |
| Power | (50/60 Hz) |
| OS Provided | No operating system |
| Color | Black |
| Dimensions (WxDxH) | 6.9 in x 16.8 in x 15.3 in |
| Weight | 18.96 lbs |
| Pricing Type | CTO |
| Environmental Standards | ENERGY STAR Qualified EPEAT Gold |
| General | |
| Type | Workstation |
| AI Level | AI PC, AI Workstation |
| Product Form Factor | Tower - 4U |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Black |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external 3.5" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 3.5" |
| Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 4.0 x4 - full-length, full-height (x1 mode, open ended) ¦ 1 (total) / 1 (free) x PCIe 4.0 x4 - full-length, full-height (open ended) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - full-length, full-height (x4 mode) ¦ 2 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode (for internal storage)) ¦ 1 (total) / 1 (free) x M.2 Card - 2280 (PCIe 5.0 x4 mode (for internal storage)) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 4.0 x1 mode and Intel CNVi wireless module) ¦ 2 (total) / 2 (free) x Flex I/O |
| Interfaces | 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 6 x USB 3.2 Gen 2 (4 front, 2 rear) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 2 x DisplayPort 1.4 ¦ 3 x USB 2.0 - Type A ¦ 2 x USB 3.2 Gen 2x2 (charging) ¦ 1 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | UL, CB, CCC, FCC, RoHS, FIPS 140-2, WEEE, ICES, CEC, ERP, CECP, CEL, BIS, low halogen |
| Pricing Type | CTO |
| RAM | |
| Installed Size | 0 GB |
| Technology | DDR5 SDRAM |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 4 (empty) |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 1200 watt |
| Efficiency | 92% |
| Power Factor Correction | Yes (active) |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 85% RH (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA/NVMe |
| Controller Interface Type | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | No graphics |
| Video Interfaces | DisplayPort |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 6.9 in |
| Depth | 16.8 in |
| Height | 15.3 in |
| Weight | 18.96 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23.2 in |
| Shipping Depth | 19.3 in |
| Shipping Height | 11.6 in |
| Shipping Weight | 27.56 lbs |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA1851 Socket |
| Chipset Type | Intel W880 |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
