AI Workstation - tower 4U - 1 x Core i9 i9-14900K / up to 6 GHz - RAM 64 GB - SSD 2 TB - HP Z Turbo Drive, NVMe, TLC - T1000 - Gigabit Ethernet - Win 11 Pro - monitor: none - keyboard: US - black - with HP Wolf Pro Security Edition (1 year)
| Main Specifications | |
|---|---|
| Product Description | HP Workstation Z2 G9 - tower - AI Workstation - Core i9 i9-14900K 3.2 GHz - 64 GB - SSD 2 TB - US - with HP Wolf Pro Security Edition (1 year) |
| Type | Workstation - tower - AI Workstation |
| Height (Rack Units) | 4U |
| Localization | Language: English / region: United States |
| Processor | 1 x Intel Core i9 (14th Gen) i9-14900K / 3.2 GHz (up to 6 GHz, (24-core) |
| Processor Socket | LGA1700 Socket |
| Processor Main Features | Intel Turbo Boost Technology |
| Cache Memory | 36 MB L3 cache |
| Cache Per Processor | 36 MB |
| RAM | 64 GB (installed) / 128 GB (max) - DDR5 SDRAM - ECC |
| Storage Controller | SATA/NVMe (SATA 6Gb/s / PCIe 4.0 x4 (NVMe)) |
| Hard Drive | SSD 2 TB - PCI Express 4.0 - M.2 - HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
| Optical Storage | No optical drive |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Graphics Controller | PCIe 3.0 x16 - NVIDIA T1000 / Intel UHD Graphics 770 |
| Video Memory | 4 GB GDDR6 SDRAM |
| Networking | 1GbE |
| Keyboard | US |
| Power | (50/60 Hz) |
| OS Provided | Windows 11 Pro |
| Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7 |
| Color | Black |
| Dimensions (WxDxH) | 6.7 in x 15.2 in x 14 in |
| Weight | 13.67 lbs |
| Carbon Footprint | 610 kg carbon emissions |
| Manufacturer Warranty | Limited warranty - parts and labor - 3 years - on-site |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| General | |
| Type | Workstation |
| AI Level | AI Workstation |
| Product Form Factor | Tower - 4U |
| Sensors | HP Tamper Lock |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Black |
| Localization | Language: English / region: United States |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 0 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 (x1 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (for SSD) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (for WLAN) |
| Interfaces | 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 2 x DisplayPort 1.4 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x USB 3.2 Gen 1 ¦ 4 x Mini DisplayPort 1.4 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen, ISV Certified |
| RAM | |
| Installed Size | 64 GB (installed) / 128 GB (max) |
| Technology | DDR5 SDRAM - ECC |
| Effective Memory Speed | 2400 MHz |
| Rated Memory Speed | 2400 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 2 (empty) |
| Configuration Features | 2 x 32 GB |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), Intel Active Management Technology (AMT), PXE 2.1 support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 90-269 V (50/60 Hz) |
| Power Provided | 700 watt |
| Efficiency | 92% |
| Power Factor Correction | Yes (active) |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 85% RH (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA/NVMe |
| Controller Interface Type | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| Channel Qty | 4 |
| RAID Level | RAID 0, RAID 1 |
| Cache Memory | |
| Installed Size | L3 cache - 36 MB |
| Cache Per Processor | 36 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Interface Type | PCIe 3.0 x16 |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Graphics Processor | NVIDIA T1000 / Intel UHD Graphics 770 |
| Video Memory | 4 GB GDDR6 SDRAM |
| Bandwidth | 160 GBps |
| Video Interfaces | DisplayPort |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7 |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 2 TB |
| Interface Type | PCI Express 4.0 |
| Features | HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 6.7 in |
| Depth | 15.2 in |
| Height | 14 in |
| Weight | 13.67 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 11.6 in |
| Shipping Depth | 19.3 in |
| Shipping Height | 20.4 in |
| Keyboard | |
| Keyboard Name | HP 320K |
| Localization & Layout | US |
| Mouse | |
| Mouse Name | HP 320M |
| Processor / Chipset | |
| CPU | Intel Core i9 (14th Gen) i9-14900K |
| Clock Speed | 3.2 GHz (P-core) / 2.4 GHz (E-core) |
| Max Turbo Speed | 6 GHz (P-core) / 4.4 GHz (E-core) |
| Number of Cores | 24-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| L2 cache | 32 MB |
| CPU Upgradability | Upgradable |
| Processor Main Features | Intel Turbo Boost Technology |
| CPU Socket | LGA1700 Socket |
| Chipset Type | Intel W680 |
| Sustainability Information | |
| Carbon Footprint | 610 kg carbon emissions |
| Manufacturing (kg CO2e) | 242 |
| Logistics (kg CO2e) | 2 |
| Use (kg CO2e) | 362 |
| EOL (kg CO2e) | 3 |
| Total Carbon w/o Use Phase (kg CO2e) | 248 |
