Hewlett Packard Enterprise - HPE ProLiant ML350 Gen11 Base

Server - tower 4U - 2-way - 1 x Xeon Silver 4410Y / up to 3.9 GHz - RAM 32 GB - SATA/SAS/NVMe - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet - no OS - monitor: none - BTO

Hewlett Packard Enterprise
P53566-001
0190017594316
N/A
New

Price: $11,946.00

MSRP: $11,946.00
Total Available: 17
Promotional Price
$2997.25
10/30/2024

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HPE ProLiant ML350 Gen11 Base - tower Xeon Silver 4410Y 2 GHz - 32 GB - no HDD
Type Server - tower
Height (Rack Units) 4U
Localization Region: Americas
Server Scalability 2-way
Processor 1 Xeon Silver 4410Y / 2 GHz (up to 3.9 GHz, (12-core)
Processor Main Features Intel Turbo Boost Technology
Cache Memory 30 MB L3 cache
Cache Per Processor 30 MB
RAM 32 GB (installed) / 4 TB (max) - DDR5 SDRAM - Advanced ECC
Storage Controller RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) - OCP (HPE MR408i-o Gen11 SPDM)
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage No optical drive
Video Memory 16 MB
Networking 1GbE
Power Redundancy Optional
OS Provided No operating system
Dimensions (WxDxH) 6.9 in x 28 in x 18.2 in
Weight 72.38 lbs
Pricing Type BTO
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site - response time: next business day
General
Type Server
Product Form Factor Tower - 4U
Built-in Devices LED panel
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability 2-way
Hot-Swap Bays Qty 8
Localization Region: Americas
Expansion / Connectivity
Bays 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots 4 (total) / 4 (free) x PCIe 5.0 x16 (x8 mode)
Interfaces 1 x VGA ¦ 1 x serial ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO - RJ-45 ¦ 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 top) ¦ 1 x USB 2.0 (1 bottom) ¦ 1 x HPE iLO - Type A (1 in front)
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Miscellaneous
Included Accessories 3 standard fans
Theft/Intrusion Protection Security lock slot (cable lock sold separately), padlock eye
Security Slot Type Kensington security slot
Compliant Standards ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, FIPS 140-3, ErP Lot 9
Pricing Type BTO
RAM
Installed Size 32 GB (installed) / 4 TB (max)
Technology DDR5 SDRAM - Advanced ECC
Effective Memory Speed 4000 MHz
Rated Memory Speed 4800 MHz
Form Factor DIMM 288-pin
Slots 16 (total) / 15 (empty)
Features Registered, dual rank, 8-channel memory architecture, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only
Configuration Features 1 x 32 GB
Networking
Interface (Bus) Type Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports 4 x Gigabit Ethernet
Ethernet Controller Broadcom BCM5719
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol SNMP 3, SMASH CLP
Remote Management Controller Integrated Lights-Out 6
Features Wake on LAN (WoL), PXE support
Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 100-120/200-240 V
Power Provided 800 Watt
80 PLUS Certification 80 PLUS Titanium
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% (non-condensing)
Storage Controller
Type 1 x RAID - OCP
Controller Interface Type Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name HPE MR408i-o Gen11 SPDM
Channel Qty 8
RAID Level RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60
Buffer Size 4 GB
Cache Memory
Installed Size L3 cache - 30 MB
Cache Per Processor 30 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Video Memory 16 MB
Video Interfaces VGA
Operating System / Software
OS Provided No operating system
Hard Drive
Type No HDD
Dimensions & Weight
Width 6.9 in
Depth 28 in
Height 18.2 in
Weight 72.38 lbs
Processor / Chipset
CPU Xeon Silver 4410Y
Clock Speed 2 GHz
Max Turbo Speed 3.9 GHz
Number of Cores 12-core
CPU Qty 1
Max CPU Qty 2
CPU Upgradability Upgradable
Processor Main Features Intel Turbo Boost Technology
Chipset Type Intel C741
Sustainability Information
ENERGY STAR Certified Yes
